Product Details:
|
| Model NO.: | XINRUI-G1 | Model No.: | 4bt9, 4et9, 12V2, 11y9, 11V5, 12A2 |
|---|---|---|---|
| Circular Degree: | <0.1 | Technics: | Sinter |
| Working Style: | Tool Grinding | Grinding Wheels For Gashing: | Grinding Tools For Flute Grinding |
| 1A1 1V1 14A1 14f1r 14f1 6A9 11V9 1: | Diamond & CBN Grinding Wheels For CNC Tools | Peel Grinding Of Tungsten Carbide Tool: | Shape 6A2h 11A2 11A2b 2A2t 11A2h 12A2t 15A2 |
| Shape 1A1r Shape 1A1rh: | Cut-off Grinding Of Tungsten Carbide Blanks | Transport Package: | By Box |
| Specification: | Diamond | Trademark: | XINRUI |
| Origin: | China Henan | HS Code: | 6804221000 |
| Supply Ability: | 10000pieces/Year | Package Size: | 80.00cm * 50.00cm * 30.00cm |
| Package Gross Weight: | 1.000kg | Lead Time: | 15 Days (1 - 100 Pieces) To Be Negotiated ( > 100 Pieces) |
| Manufacturing Process: | Sintered | Shape: | Cup-Shaped |
| Bonding Agent: | Metal | Customization: | Available | Customized Request |
| Shipping Cost : | About Shipping Cost And Estimated Delivery Time. | : | Initial Payment Full Payment |
| Currency: | US$ | Return&refunds: | You Can Apply For A Refund Up To 30 Days After Receipt Of The Products. |
Diamond and CBN Wheels 1A1 1V1 11V9 12V9 1A1R for the Fluting, Gashing and Clearance Angles of Tungsten carbide milling cutters, Tungsten carbide drill bits, Hss milling cutters
THE CNC GRINDING WHEEL PROGRAM FOR ROTATING CUTTING TOOLS
Tungsten carbide milling cutters
Tungsten carbide drill bits
Hss milling cutters
FLUTING GRINDING SHAPE 1A1, 1V1,
Optimized profile retention together with a high material removal rate wit diamond or CBN available
REGRINDING
Standard grinding tools with diamond or CBN for regrinding and tool manufacturing with balance profile retention and materials removal rate
GRINDING OF CLREARANCE ANGLES AND FACE GEOMETRIES
Cup grinding wheels with optimum edges stability with diamond or CBN available
1A1 1V1 14A1 14F1R 14F1 6A9 11V9 12V9 1A1R 12A2 4BT9 4B2 4ET9
Diamond and CBN Wheels 1A1 1V1 11V9 12V9 1A1R for the Fluting, Gashing and Clearance Angles of Tungsten carbide milling cutters, Tungsten carbide drill bits, Hss milling cutters
| MODEL | Outside diameter(mm) | T (mm) | Altitude (mm) | w (mm) | X (mm) |
| 4B1 | 150 | 24 | 20,31.75 | 4,6 | 2,3 |
| 200 | 20 | 20,31.75 | 6 | 3,6 | |
| 250 | 20 | 20,31.75 | 8 | 6,8 | |
| 4A9 | 80 | 6 | 20,25,31.75,40 | 10 | 6 |
| 100 | 8 | 20,31.75 | 10 | 6 | |
| 150 | 8 | 20,31.75 | 10 | 6 | |
| 3A1 | 100 | 6 | 20,31.75 | 6 | 1,4 |
| 125 | 8 | 20,31.75 | 6,8 | 4,1.5 | |
| 150 | 6,8 | 20,31.75 | 6,8 | 4,2 |
Our company has three brands: XINRUIDIAMOND XIAOMOFANG DIMING
